DSP controlled Glass Relief CNC Engraving machine with HIWIN square linear rail TYE-1318C

    Buy cheap DSP controlled Glass Relief CNC Engraving machine with HIWIN square linear rail TYE-1318C from wholesalers

    Buy cheap DSP controlled Glass Relief CNC Engraving machine with HIWIN square linear rail TYE-1318C from wholesalers
    • Buy cheap DSP controlled Glass Relief CNC Engraving machine with HIWIN square linear rail TYE-1318C from wholesalers

    DSP controlled Glass Relief CNC Engraving machine with HIWIN square linear rail TYE-1318C

    Ask Lasest Price
    Brand Name : TYE
    Model Number : TYE-1318C
    Certification : CE
    Payment Terms : TT in advance,Western union,moneygram
    Supply Ability : 300 pcs/month
    Delivery Time : 7-10 working days
    • Product Details
    • Company Profile

    DSP controlled Glass Relief CNC Engraving machine with HIWIN square linear rail TYE-1318C

    DSP controlled Glass Relief CNC Engraving machine with HIWIN square linear rail TYE-1318C
    DSP controlled Glass Relief CNC Engraving machine with HIWIN square linear rail Machine Features:
    1. A three-axis linear guide running smoothly, and high precision.
    2. Complete machine using seamless welding steel structure, rigid, and no deformation, the dorsal surface lining plate, strength, steel and good.
    3. Constant power spindle motor, cutting intensity, high efficiency.
    4. The U-disk embedded control system completely offline to work more convenient and flexible.
    DSP controlled Glass Relief CNC Engraving machine with HIWIN square linear rail parameters:
    ModelTYE -1318C
    Working Area1300*1800*300mm (51.2 x 70.8x 11.8")
    Machine Structure
    Thick-walled square tube lathe bed
    and T-slot table of sectional material
    Work HoldingBy Clamps
    Precision0.0 1 mm
    Positioning accuracy0.0 1 mm
    Repeatability0. 03 mm
    Idling Speed17 ,000mm/min
    Working Speed10 ,000mm/min
    Spindle power3KW water-cooling ,variable speed
    Spindle rotating0-24000rpm
    Available Toolsφ 3.175~ φ 12.7
    Drive SystemStepper motor
    Working VoltageAC380V ± 30V, 50HZ
    Command CodeG Code (*.nc, *.mmg, *.u00, etc.), *.eng
    Control SystemNcStudio( DSP,Mach 3 optional)
    Compatible SoftwareCompatible with any software generating G code file in Window 98/XP/7
    Overall Dimensions2350*1800*1700

    DSP controlled Glass Relief CNC Engraving machine with HIWIN square linear rail details:

    DSP controlled Glass Relief CNC Engraving machine with HIWIN square linear rail Samples:


    Quality DSP controlled Glass Relief CNC Engraving machine with HIWIN square linear rail TYE-1318C for sale
